INDUSTRIAL DRAIN - (760.503.160)
×
![]()
Part Of the Series: Drain-No membrane-305
Type no.: 760.503.160
EAN no.: 5705499109566
VVS no.: 153050063
LVI no.: 3303528
Size: Ø305
INDUSTRIAL DRAIN
-Floor: resin
-Frame: Ø305mm
-Outlet: Ø160mm, vertical
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Adjustable | No |
| Field Of Application | Industrial |
| Floor | Resin |
| GWP total Co2 eq. for A1-A3 per product | 34,69kg |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Membrane Type | No Membrane |
| Minimum Height (mm) | 378 |
| Number of Inlets | 0 |
| Number of inlets (inch) | 0 |
| Holes for screws in drains | 0 |
| Outlet Diameter ('') | 6 |
| Outlet Diameter (mm) | 160 |
| Outlet Direction | Vertical |
| Shape of frame | Round |
| Size of Frame (inch) | Ø12 |
| Size of frame (mm) | Ø305 |
| Weight (kg) | 5,85 |
| Weight (lbs) | 12,9 |
-
Downloads
-
Approvals and standards
For approvals and standards information, please refer to the below certificates.
